Samsung Washing Machine dimensions and clearance requirements
Samsung washing machine installs are easier to shortlist when cabinet space and service room are checked together. Use these figures as the first pass before you compare exact models. Current guide figures are 20mm at each side, 50mm at the rear and 50mm above. The side gap is 10mm wider than the usual category baseline. The rear allowance is 50mm tighter than the default figure. The top allowance is 40mm taller than the default figure.
Side clearance
20mm
20mm
Rear clearance
50mm
50mm
Top clearance
50mm
50mm
Models in database
39
39
Door swing confirmed
1 of 39 Research in progress
1 of 39 Research in progress
Installation Tips
- Measure with the water taps and waste hose in mind, not just the cabinet box.
- Leave room for the hoses to curve naturally so the machine can sit square once it is levelled.
- If the laundry door swings inward, measure that arc before the machine is delivered.
Current Samsung Models
WW11CG60ADLE
W 600mm × H 850mm × D 600mm
WW90DG6U3ALB
W 600mm × H 850mm × D 595mm
WW90DG6U3ALE
W 600mm × H 850mm × D 595mm
Previous / Archived Models
Older reference models are kept for replacement searches and historical size lookups. Use the active models above when you want a current retailer link.
WA10J7750GW
W 686mm × H 1115mm × D 744mm
WA70F5G4DJW
W 610mm × H 1100mm × D 672mm
WA13M8700GV
W 686mm × H 1077mm × D 744mm
