How to install Samsung refrigerator
Samsung Fridge dimensions and clearance requirements
Samsung fridge installs often hinge on the top gap, especially below overhead cabinetry. Start with the clearances here, then check height and depth on the models that still look promising. Current guide figures are 50mm at each side, 50mm at the rear and 100mm above. The side gap is 10mm wider than the usual category baseline. The rear allowance is 25mm deeper than the default figure. The top allowance is 50mm taller than the default figure.
Side clearance
50mm
50mm
Rear clearance
50mm
50mm
Top clearance
100mm
100mm
Models in database
48
48
Door swing confirmed
4 of 48 Research in progress
4 of 48 Research in progress
Installation Tips
- Samsung fridge installs are often limited by the top gap, so measure to the underside of the cabinet door and not the cabinet box alone.
- If the opening is tight, check the hinge cover height before you compare cabinet heights.
- Leave space to level the front feet after the cabinet is in place.
Current Samsung Models
SRF9400BFH
W 912mm × H 1830mm × D 723mm
SRF9800BFH
W 912mm × H 1830mm × D 861mm
SRF9700BFH
W 912mm × H 1797mm × D 723mm
Previous / Archived Models
Older reference models are kept for replacement searches and historical size lookups. Use the active models above when you want a current retailer link.
SFP345RW
W 595mm × H 1853mm × D 694mm
SRP405RW
W 595mm × H 1853mm × D 694mm
SRF717CDBLS
W 908mm × H 1825mm × D 733mm
