Miele Dishwasher dimensions and clearance requirements
Miele dishwasher fit checks usually come down to side room, service depth and how tidy the cavity opening really is. Start with these figures, then move to the model list. Current guide figures are 20mm at each side, 50mm at the rear and 50mm above. The side gap is 18mm wider than the usual category baseline. The top allowance is 25mm taller than the default figure.
Side clearance
20mm
20mm
Rear clearance
50mm
50mm
Top clearance
50mm
50mm
Models in database
28
28
Door swing confirmed
23 of 28 Research in progress
23 of 28 Research in progress
Installation Tips
- Measure the cavity after the floor finish and kickboard are installed, not before.
- Check the service void and hose route at the rear before you commit to the cabinet depth.
- Level the dishwasher with the door open once the side gaps are confirmed.
Current Miele Models
G7130SCCLST
W 598mm × H 845mm × D 600mm
G7609SCIXXLCLST
W 598mm × H 845mm × D 570mm
G7609SCUXXLCLST
W 598mm × H 845mm × D 570mm
Previous / Archived Models
Older reference models are kept for replacement searches and historical size lookups. Use the active models above when you want a current retailer link.
G 6999 SCVi XXL
W 598mm × H 910mm × D 570mm
G 6xxx
W 598mm × H 870mm × D 570mm
G 5210 SC
W 598mm × H 845mm × D 600mm
