Hisense Washing Machine dimensions and clearance requirements
Hisense washing machine installs are easier to shortlist when cabinet space and service room are checked together. Use these figures as the first pass before you compare exact models. Current guide figures are 20mm at each side, 50mm at the rear and 50mm above. The side gap is 10mm wider than the usual category baseline. The rear allowance is 50mm tighter than the default figure. The top allowance is 40mm taller than the default figure.
Side clearance
20mm
20mm
Rear clearance
50mm
50mm
Top clearance
50mm
50mm
Models in database
26
26
Door swing confirmed
20 of 26 Research in progress
20 of 26 Research in progress
Installation Tips
- Measure with the water taps and waste hose in mind, not just the cabinet box.
- Leave room for the hoses to curve naturally so the machine can sit square once it is levelled.
- If the laundry door swings inward, measure that arc before the machine is delivered.
Current Hisense Models
HWF3S7514X
W 595mm × H 845mm × D 510mm
HWF3S8514X
W 595mm × H 845mm × D 540mm
HWF5I1015
W 595mm × H 845mm × D 550mm
Previous / Archived Models
Older reference models are kept for replacement searches and historical size lookups. Use the active models above when you want a current retailer link.
HWT3K8065B
W 553mm × H 975mm × D 604mm
HWFM8012
W 595mm × H 850mm × D 600mm
HWGA8014
W 600mm × H 850mm × D 625mm
