Fisher & Paykel Dryer dimensions and clearance requirements
Fisher & Paykel dryer installs look simple until the wall gap, venting plan and door access are counted properly. This page gives you the clearance numbers first so the shortlist stays realistic. Current guide figures are 20mm at each side, 50mm at the rear and 50mm above. The side gap is 10mm tighter than the usual category baseline. The rear allowance is 30mm tighter than the default figure. The top allowance is 150mm tighter than the default figure.
Side clearance
20mm
20mm
Rear clearance
50mm
50mm
Top clearance
50mm
50mm
Models in database
24
24
Door swing confirmed
2 of 24 Research in progress
2 of 24 Research in progress
Installation Tips
- Check the wall gap and lint service access before the dryer is pushed fully home.
- If the dryer is stacked, measure from the finished floor to the underside of the shelf or cupboard above.
- Confirm the venting plan before delivery if the model is not condenser or heat-pump.
Current Fisher & Paykel Models
DH1060DG5
W 602mm × H 850mm × D 682mm
DH1060RG5
W 602mm × H 850mm × D 682mm
DH8060J5
W 602mm × H 850mm × D 682mm
Previous / Archived Models
Older reference models are kept for replacement searches and historical size lookups. Use the active models above when you want a current retailer link.
DH8060P1
W 600mm × H 850mm × D 650mm
DH8060P3
W 600mm × H 850mm × D 650mm
DH9060FS1
W 600mm × H 850mm × D 670mm
